Síťová tiskárna

We have a new network printer and a new print queuing system! The printer is located in the entry hall of the Sinkuleho dormitory. Old printing accnouts will be transfered automatically in the following days. If you need your printing account transferred immediately, please contact the printer managers: tisk@sin.cvut.cz

The printer can be found in the entry hall of the Sinkuleho dormitory (3rd hall, where the reception is), by the baguette vending machine.

Print history and account details can be found on https://print.sin.cvut.cz after logging in to MyQ system.

Parameter overview of printer TOSHIBA e-STUDIO2505AC and MyQ system on Sinkuleho dormitory:

Colour printing Colour, B&W
Paper formats A4, A3
Duplex Yes
Scanner/copier Two-sided feeder, panel
Print job submission IPPS, Email, Web interface, Android application, iOS application
Scan job submission User's email, Network drive
Resolution up to 600dpi

Printer's technical specification sheet: PDF

Pricing and recharging your printing account

Size B&W Color
A4 0,80 Kč 2,00 Kč
A3 1,60 Kč 4,00 Kč

Prices include VAT (DPH) of 21%.

You can recharge your printing account with a czech wire transfer (this requires a czech bank accnout, SEPA/SWIFT is not supported):

Payment with incorrect symbols will not be processed!

Account No.: 99924050/2010
Variable symbol (VS): <Your SINIS UID>
Specific symbol (SS): 900

Payments get processed usually in less than 10 minutes, after which you will receive a confirmation email. In case your payment wasn't processed correctly, and has not been assigned in ~2 days, please contact the printer managers: tisk@sin.cvut.cz, same for refunds and chargebacks.

MyQ System

Log in to the MyQ system on address https://print.sin.cvut.cz.

MyQ is a printing management system. It allows for submitting print jobs to the server. They are released after authentication on the physical printer (release-on-tap). It offers features such as print job submission and monitoring, user authentication, mobile printing and scanning.

You can log in to MyQ using your username (likely name.surname), or your own (SINIS) email and SINIS password on https://print.sin.cvut.cz.

You can submit, or monitor jobs, view spent and recharged credits on your printing account.

Printing

Web interface

You can submit a print job straight from the web interface. This is especially suitable for occasional printing.

After logging in, on homepage in section Jobs > Print file…

MyQ homepageMyQ print dialog

MyQ web interface can only be accessed from the CTU network.

Email attachment

Print jobs can also be submitted as attachments to an email sent to printer@sin.cvut.cz. The default settings are colour, simplex and no toner saving. This can be changed by adding the following keywords into the email's Subject field:

#color / #mono Colour / B&W printing
#simplex / #duplex One-sided / Two-Sided printing
#ecooff / #ecoon Economical / Non-economical toner usage

Job admission via email takes roughly 30 seconds. If an error occurs (e.g. unsupported format), the system returns an error message.

Printing over the network using IPPS

Print jobs can be submitted over the IPPS protocol (Internet printing protocol secured) on address ipps://print.sin.cvut.cz:443/queue/Default, but it's necessary to add a username that corresponds to your SINIS username (likely name.surname).

Adding a printer on Linux: (it's necessary to change the username!):

lpadmin -p Sincoolka-MyQ -E -v ipps://username@print.sin.cvut.cz:443/queue/Default -m everywhere

Adding a printer on Windows using PowerShell (it's necessary to edit the username!):

Add-Printer -IppURL https://username@print.sin.cvut.cz:443/queue/Default

Execution takes up to several minutes. If you wish to use the graphical interface to set up a printer on WIndows, use https://uzivatelske.jmeno@print.sin.cvut.cz:443/queue/Default as the printer's address.

Network printing is only available from the CTU network.

Network printing using a client application

Android: https://play.google.com/store/apps/details?id=com.myqsolution.myqx

iOS: Search and install MyQ X on the App Store.

Scan

Scanning on both panel and feeder can be performed with a resolution of up to 600dpi. Feeder scan is prioritized if paper is present (a blue indicator light is on).

Scan to email

Scanning and sending file(s) to the user's (personal, or “school email” in SINIS) email. The system sends the scan as an attachment up to 24MB, otherwise, a download link on the MyQ system is sent instead. The system sends emails from the address printer@sin.cvut.cz - check the SPAM folder in case no email was received.

The default settings are a 200dpi PDF with JPEG compression, so the resulting file can easily be sent as an attachment. That corresponds to tens of coloured pages with text and colour graphics.

Scan to drive

Scan to drive works, however

Drive access does not work yet. Comming soon(TM)!

Scanning to drive is preferable for bigger files or for better convenience. You can access your scans via FTP or a web interface, where you log in using your SINIS credentials.

The default setting are 300dpi PDF with JPEG compression.

MyQ drive is only accessible from the CTU network.
